1

Veranda lounge (504 seats)

2

Dance floor

3

Air-conditioning shaft

4

Funnel casing

5

Rear semi-enclosed pool's glass roof

6

Pizzeria/Italian. restaurant & central oven

7

Crew's stair's tower with elevator. or lift

8

Lifeboats (20X150 pax) & rescue boats (2X25pax)

9

Linen, accessor., dishes prepa w. dumbwaiter & dirty crockery area

10

Funnel casing with exhaust silencers & filters

11

Dish washing (3 restaurants & H, I, J lounges) & pizzeria's crockery

12

Digital datas surveillance & control network system & terminal

13

Arts Gallery

14

Slot machines

15

Workshop & courses (drawing, painting, tapestry, sculpture, photo)

16

Museum and its round glass showcase gallery

17

Conference rooms (2x66 or 1x132 seats)

18

Conference rooms (3 x 18 seats)

19

3 intimate lounges

20

Video games

21

Theatre (876 seats)

22

Crew's office

23

Discotheque (two levels, 116 seats)

24

Crew's staterooms (double)

25

Front semi-enclosed crew's promenade (& vent units)

26

Semi-enclosed pool mezzanine

27

Fitness center

28

Gastronomic restaurant

29

Theatre balcony's entrance

30

Exotic restaurant

31

Main hall, 2nd & 3rd levels

32

Main theatre entrance

33

Anchoring devices machinery & aux alternators

34

Rear semi-enclosed pool & whirlpools

35

Spa center & whirlpools

36

Body cares, massages & hairdresser

37

Outside promenades

38

Nursery & 3-8 year old children's play room

39

Ice cream parlour

40

Cigar club

41

Internet café

42

3-8 children's playroom area

43

Bridge player room

44

Champagne bar

45

Under theatre: secu room, life jackets store, toilets & cinema ceiling.

46

Theatre's stage

47

Wings with dressing room accessories

48

Anchoring devices machinery & spare ropes/bosco store

49

Rear mooring area &semi-enclosed crew's promenade

50

Rear vent units

51

Rear semi-enclosed pool's pumps & heating machinery

52

Rear poll's tank

53

Crew's bar

54

Standard cabin

55

Second hall entrance

56

Irish pub gallery

57

2 separate cruise staff members briefing rooms

58

2 separate cruise staff members offices

59

Cruise staff members dining rooms butlery & self-service ramp

60

2 separate cruise staff members dining rooms

61

Casino's bank & bar

62

Casino with bar (220 slot machines, 8 Blackjack tables & 6 roulettes)

63

Main hall entrance

64

Informations, purser, shore excurs. desks & entrance cocktail bar

65

Cinema & shore excursions briefing room (216 seats)

66

Artist performers staterooms (30 x 2)

67

Cabin service stores &admin. linen, accesso., hyg. products, trolleys

68

Artist performers dressing room

69

Passengers self-service laundries (2)

70

Crew's briefing/studies and rest fore room

71

Crew's gymnastic and sports fore room

72

Crew's fore TV room & playroom

73

Fore crew's bar

74

Chains passageways

75

Fore store

76

TV studio

77

Aft mooring machinery & spare ropes stores

78

Crew's briefing/studies and rest rear room

79

Aft crew's TV room & playroom

80

Aft mooring machinery & spare ropes stores

81

Cabins accessories and hygienic products stores

82

Aft mooring machinery

83

Low-ranking butlery & dish-washing

84

Low-ranking officers dining room

85

Toilets bloc (cruise staff, kitchens, crew)

86

Crew's cabins (2x2 berths - kitchen's staff)

87

Hospital, 2 waiting rooms, morgue, 2 surgery rooms, radio room

88

Hospital, bedrooms (4x1 + 4x2 + 2x3 beds) + medical staff accom.

89

Additional crew storage room with individual safe racks

90

Security's equipment store CO2 extinguish system cyl.

91

Chains shafts and storage

92

Crew's gymnastic and sports aft room

93

Enclosed crew's pool & dressing room

94

Kitchen's administration center

95

Crew's dishes storage

96

Kitchens (see details below in A & B captions)

97

2 levels food & supplies reception with  large elevator (deck N too)

98

Garbage area/shaft with direct access from kitchen prepa. rooms

99

Security room n"3 with dressing room & secu equipments

A1

Final dishes preparation, storage & dispatching (to butleries) area

A2

Cooking room (electric stoves, steam, ...)

A3

Kitchen staff's dressing room & bathroom

A4

Grill, roaster & broiler

A5

Confectionery room

A6

Hors d'oeuvre & salad preparation

A7

Bakery

A8

Fridges 2/6°C, defrost & storage

A9

Butcher's & fish preparation with elevator from food stores

B1

Fruits & vegetables preparation with elevator (from food storage)

B2

Room service preparation area with 2 dumbwaiters to upper decks

B3

Cooking ustensils dish washing & hyg. products & equipment room

B4

Crockery's storage

B5

M.E.S. systems (2X430 pax) & liferafts (48X40 pax)

B6

Luggage loading and transit area

B7

Crew's cabins (2x2 berths)

B8

Crew's dining room (320 seats)

B9

Crew's self-service ramp

C1

Crew's dining room wastes area

C2

Crew's butlery & dishes preparation

C3

Crew's dish washing

C4

Food & supplies administration center

C5

Food & supplies reception & sorting

C6

Cold rooms *** -18/-2°C (meat, beef, chicken, fish, ice...)

C7

Cold rooms *2/6°C (fruits, vegetables, milk, cheese, cooked pork...)

C8

Food stores: dry food, flour, sugar, potatoes, canned food, flowers...

C9

N.A.

D1

Purser central administration

D2

Luggage sorting

D3

Emergency diesel alternator room (2)

D4

Steering machinery, pods base & hydraulic/electric devices

D5

Air conditioning plants (3, aft, central & fore)

D6

Paint store

D7

Chemicals store

D8

Decompression chamber

D9

Security's equipment store

E1

Administration offices (various departments) & prison

E2

Crew hold, spares / consumables & spare furniture stores

E3

Spare decoration items and materials, curtains, moquettes, carpets...

E4

Rebus store:broken items, accessories or furniture

E5

CO2 extinguish system cylinders for main engine rooms

E6

Electric devices, spares & lamps store. Oxygen store & production

E7

Crew's co-op and co-op store

E8

Main diesel alternators(4)

E9

Main engines fuel pumps, separators, heaters.

F1

Mechanic & joiner's workshop / Spares and woods store

F2

PC machines and store (miscellaneous)

F3

Various drinks cold rooms & stores (with large elevator)

F4

PC security (auxiliary)

F5

Security room n"1 & 2 with dressing room & secu equipments

F6

Additional crew storage rooms with individual safe racks

F7

Additional crew storage room with individual safe racks

F8

Crew's linen store

F9

Dirty linen store and crew 's staterooms administration office

G1

Electric pods (4, 2 rear ones turning & 2 fore ones fixed)

G2

Aft waste waters treatment plant

G3

Aft HVAC system

G4

Electric boards, synchro-convertors, aux separat./heaters, pumps...

G5

Auxiliary diesel engines (6)

G6

Fuel tanks

G7

Ballasts pumps & fresh water's pumps and filters

G8

Evaporator / desalination fresh water production plant

G9

Compactor & wastes treatment & stocking

H1

Central HVAC system

H2

Central waste waters treatment plant

H3

Electric boiler (hot water and steam)

H4

Compressors room (board use and pneumatic devices)

H5

Supply and transfer fuel pumps rooms (2)

H6

Crew's clothing office and store

H7

Printing & publications workshop

H8

Ballasts pumps & fresh water's pumps and filters

H9

bedding store

J1

Crew's self-service laundry

J2

Linen stores

J3

Laundry

J4

Bow's propellers (3 X 2.000 kW)

J5

N.A.

J6

Waste waters storage (double bottom)

J7

Water's ballasts (fresh water & sea water - double bottom)

J8

Lub oil & waste lub oil tanks & purifiers

J9

Stabilizers machinery and fins

K1

Emergency electric accumulators

K2

Double bottom (as far as O deck, sea water ballasts in the bottom Q deck

K3

Crew's sauna, dressing room & pool tank

K4

Anchors and chains storage

K5

Hot water production boiler (Diesel exhaust gas use)

K6

Hot water tanks (3, 100+77+70 tons)

K7

Hot water production exchanger (Diesel cooling water's use)

K8

N.A.
